Sistem Interkom Kendaraan Seri 3800 dirancang untuk mengatasi masalah komunikasi di lingkungan dengan tingkat kebisingan tinggi, terutama yang berkaitan dengan operasi darurat selama respons panggilan dan di lokasi kejadian. Sistem ini terdiri dari modul antarmuka, kabel yang sesuai, dan headset peredam bising yang kokoh namun nyaman.

Sistem ini memberikan komunikasi yang jelas dan jernih kepada petugas pemadam kebakaran/penyelamatan/EMS melalui perangkat tersebut, sekaligus meredam kebisingan latar belakang dan melindungi pendengaran pengguna. Sistem Seri 3800 juga menyediakan konektivitas ke radio seluler, sehingga semua personel dapat memantau semua lalu lintas radio yang terhubung dan stasiun-stasiun tertentu dapat menerima kemampuan transmisi.

INTERCOM MODULE - 3800 SERIES

U3800 Master Station

Heart of any 3800 system configuration (one each required per system)



  • Provides crisp, clear communication in demandingenvironments
  • Hands-free, full-duplex, intercom communications
  • Compatible with all 3000 Series Headsets
  • Accommodates up to two headset users (should be installedwhere radio transmit function is not required)
  • Dual headset jacks with individual user volume controls
  • System master volume control
  • External 1-amp “slo-blo” fuse/holder assembly
  • MS-type connectors for system connections with weatherprotective caps
  •      2 each System Input/Output connectors
  •      1 each Power connector
  • Illuminated on/off switch, push-button
  • Surface mount installation kit included
  • Durable, weather-resistant enclosure

Model H3432

Over-the-Head, Dual-Ear Style

  • M-7A noise canceling electret microphone
  • Hybrid wire/flex boom assembly, 280° rotating, for perfect microphone placement on left or right side
  • Dynamic earphone elements
  • Advanced Undercut Gel Ear Seals for superior comfort
  • Microphone on/off switch
  • Air-flow, pillow head pad (4-chamber), eliminates “hot spots”
  • 6 ft. extended coil cord
  • Carbon steel hardware, chrome finish
  • Independently Certified NRR: 23dB

U3802 Remote Headset Station

Same as U3801, but provides a path for further expansion

  • Expands the system beyond the Master Station
  • Accommodates one Headset
  • Should be installed where radio transmit functionality is not required
  • Provides connection for further system expansion
  • Simple installation
  • Dimensions: 5-3/8″ L x 4-3/4″ W x 3″ D

U3806 Dual Headset Intercom Station

Same as U3802, but accommodates two headsets

    • Expands the system beyond the Master Station
    • Accommodates two Headsets
    • Should be installed where radio transmit functionality is not required
    • Provides connection for further system expansion
    • Simple installation
    • Dimensions: 6-3/4″ L x 4-1/4″ W x 3-1/16″ D
    Key features include:
    • One system input connector (C38-XX)
    • Two system output connectors (C38-XX)
    • Two Headset jacks
    • Individual listen level controls

HEADSETS - 3400 SERIES

Model H3432

Over-the-Head, Dual-Ear Style

  • M-7A noise canceling electret microphone
  • Hybrid wire/flex boom assembly, 280° rotating, for perfect microphone placement on left or right side
  • Dynamic earphone elements
  • Advanced Undercut Gel Ear Seals for superior comfort
  • Microphone on/off switch
  • Air-flow, pillow head pad (4-chamber), eliminates “hot spots”
  • 6 ft. extended coil cord
  • Carbon steel hardware, chrome finish
  • Independently Certified NRR: 23dB

Model H3442

Behind-the-Head, Dual-Ear Style

  • M-7A noise canceling electret microphone
  • Hybrid wire/flex boom assembly, 280° rotating, for perfect microphone placement on left or right side
  • Dynamic earphone elements
  • Advanced Undercut Gel Ear Seals for superior comfort
  • Microphone on/off switch
  • 6 ft. extended coil cord
  • Adjustable overhead support assembly
  • Carbon steel nape-band spring, black finish, rotates for left or right side mic positioning
  • Independently Certified NRR: 23dB

Model H3492

Over-the-Head, Single-Ear Style

  • M-7A noise canceling electret microphone
  • Hybrid wire/flex boom assembly, 280° rotating, for perfect microphone placement on left or right side
  • Dynamic earphone element
  • Advanced Undercut Gel Ear Seal for superior comfort
  • Microphone on/off switch
  • Air-flow, pillow head pad (4-chamber), eliminates “hot spots” with similar 2-chamber temple pad
  • 6 ft. extended coil cord
  • Carbon steel hardware, chrome finish

Model H3441

Behind-the-Head, Single-Ear Style

    • M-7A noise canceling electret microphone
    • Hybrid wire/flex boom assembly, 280° rotating, for perfect microphone placement on left or right side
    • Dynamic earphone element
    • Advanced Undercut Gel Ear Seals for superior comfort
    • Microphone on/off switch
    • 6 ft. extended coil cord
    • Adjustable overhead support assembly
    • Carbon steel nape-band spring, black finish, rotates for left or right side mic positioning
    • Slotted dome with no earphone for hearing ambient sound
